Bafang M620 setup CAN parameters.

[jlfuente]

Has anyone used this device to refresh the parameter data of a M620 Bafang motor? Any positive experiences?

K1 Flash - setup CAN motor parameters, Firmware update and Calibration & K1 BlackBox 3 & brand new K1 BatteryBox Racing

Dear Bafang ebikers Would you like to set or tune motor controller parameters? K1 Flash is compatible with all Bafang CAN bus motors (5 pin connector with "house" shape). Also can download motor firmware for M500, M510 and M600 motors and run Calibration. Simple as 1, 2 ,3 ... 1. Insert...

www.emtbforums.com

Does it allow to do what other devices allow for UART protocol?



[Dado]

Hello.

With old M620 CAN firmares, you can not set much, everything is hardcoded. Only speed limit, wheel and circumference.

But there is latest firmware 41.1 where u can set also power levels. (Throttle speed hardcoded here - unfortunatelly)



[jlfuente]

Hello.

With old M620 CAN firmares, you can not set much, everything is hardcoded. Only speed limit, wheel and circumference.

But there is latest firmware 41.2 where u can set also power levels. (Throttle speed hardcoded here - unfortunatelly)

Thanks very much for your response.



[Dado]

Saw it just now. Sorry.
That 41.1 is 48V.



[Dado]

Here is latest thanks email from a customer from Australia - they have lot of M620 motors there. Customer did tried the latest firmware 41.1 and we trying figuring out how that Eco/Sport settings works. In original Besst programmer also possible to setup only 5 levels. Dont understand why Bafang came up with this Eco/Sport mode - and only in M620. So far it looks like ECO power is lowered over some constant. And there is hardcoded speed limits for throttle. Each PAS level has different speed for throttle: 10, 15 ,20, 25, 30 kmh. Luckily pedalling speed still possible to set. But I am afraid they will hardcode pedalling speed also soon with new firmwares.

"Regarding the 3-Sports mode, it is definitely delivering more power. Maybe I did not snap the pic at the correct time. I was riding one-handed up a hill I will do some proper testing next weekend.
Also, it is not limited to 25kmph in sports mode, I will also test this further next weekend.
All in all, this bike is now 10 x better than it was. Thank you K1

Lionel"



[Csubi]

Hello.

With old M620 CAN firmares, you can not set much, everything is hardcoded. Only speed limit, wheel and circumference.

But there is latest firmware 41.1 where u can set also power levels. (Throttle speed hardcoded here - unfortunatelly)

What's the output of 41.1?
How can I get that .bin file?



[Neeko DeVinchi]

Quick question guys,

Has anyone tried this firmware on a CANBus M620 motor?

I don't have a CANBus M620 to test it on but would appreciate feedback before passing this onto someone who has made an enquiry



[Dado]

Hello Neeko.

Have a note at this firmware it has lowered power at low PAS: 3,6,12,20,30A
Attaching version 1.2, little newer, if somebody wants to try. Is great as supports also power setting.



[Neeko DeVinchi]

Much appreciated @Dado



[mystic]

Much appreciated @Dado

How did this one turn out?



[Dado]

It is good, also with power adjustment support. Over K1 Flash, Besst Pro, Go+ or DPC010
